OS2 Singlemode Fiber Optic Patch Cord With LC Type Connector LSZH Pigtail

  • 1
  • 2

Brand Name : OEM/ ODM/ Lansan

Model Number : LC

Certification : CE/ RoHS/ ETL/ UL

Place of Origin : China

MOQ : 1000 Meters

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000 Meters/ day

Delivery Time : 10-12 Work Days

Packaging Details : 1 pcs/bag

Connection Structure : lc lc single mode patch cord

Type : Pigtail

Application : Communication

Diameter : 0.9mm

Insert Loss : < 0.20dB

HS Code : 85444929

Contact Now



OS2 Singlemode IEC Standards With LC Type Connector LSZH Pigtail







Description



  • Fiber patch cord Complies with IEC, Telcordia GR-326-CORE standard
  • Low insertion loss and high return loss
  • PC/UPC/APC polishing
  • Diameter: 0.9, 2.0, and 3.0mm
  • Single or multi mode is available
  • 4 fiber, 6 fiber, 8 fiber 12 fiber or 24 fiber is available
  • 10G fiber or LSZH cable is available
  • Excellent changeability and repeatability
  • Tensile strength: 10N
  • Operating temperature range: -40 to 80° C
  • Storage temperature range: -40 to 80° C
  • Color of cable: Yellow (SM), Orange (MM), and Aqua (OM3)



Specifications

  Insertion loss   Less than 0.3dB
  Return loss   MM more than 35dB
  SM more than 55dB
  APC more than 60dB
  Repeatability   Less than 0.2dB
  Changeability   Less than 0.1dB
  Operting termperature   -40~75
  Storage temperature   -40~75
  Tensile strength   100N
  Min. bending radius   35mm
  Length   Customized





OS2 Singlemode Fiber Optic Patch Cord With LC Type Connector LSZH Pigtail
